EC17-02-8B FTTH Distribution Box

Overview:
This 8 ports Indoor / Outdoor Wall / Pole Mounted FTTH Optical Fiber Splitter Distribution Box with Waterproof Fast Connection is used for wall mounted, pole mounted or aerial splicing and termination. It can come with 8 pcs of waterproof SC adapters to fit with SC waterproof connectors directly, which will make the outdoor cabling extremely easy by plugging into the adapters.
Click:619

Service Online：

Product Details

Datasheet Download

Features:
• Water-proof design with IP65 Protection level
• Clamping for feeder cable and drop cable, fiber splicing, fixation, Storage, distribution, etc. All in one.
• Manage fibers in a reasonable fibers radius condition
• Easy to maintain and extend the capacity
• Easy plug-in and pull out
• Suitable for the fusion splice or mechanical splice
• 8 ports cable entrance for FTTH Drop Cable

Specifications:

Material: PC+ABS
Dimensions (HxWxD): 285x170x100mm
Max. Capacity:

8 SC FC simplex adapter

Inlet: 2 port
Outlet: 8 ports
Installation way: Wall Mounted, Pole Mounted, Aerial Mounted

Next: No MorePrevious: EC17-02-8A FTTH Distribution Box
