EC17-02-8A FTTH Distribution Box

Overview:
This 8 ports Optical Fiber Distribution Box Outdoor Wall/ Pole Mounted comes with 3 fiber cable ports + 8 ports for drop FTTH fiber optic cables. It can install 8pcs of SC/ LC/ FC adapters inside the splice tray, and fiber optic pigtails can be loaded inside this box.
Click:558

Service Online：

Product Details

Datasheet Download

Features:
• Water-proof design with IP65 Protection level
• Clamping for feeder cable and drop cable, fiber splicing, fixation, Storage, distribution, etc. All in one
• Manage fibers in a reasonable fibers radius condition
• Easy to maintain and extend the capacity
• Fiber bend radius control more than 40mm
• Suitable for the fusion splice or mechanical splice
• 8 ports cable entrance for FTTH Drop Cable

Specifications:

Material: PC+ABS
Dimensions (HxWxD): 220x200x60mm
Max. Capacity:

8 SC or FC simplex adapter

8 LC duplex adapter

Inlet: 3 port
Outlet: 8 ports
Installation way: Wall Mounted, Pole Mounted
