8 Ports

EC17-01-8D FTTH Terminal Box

Overview:
The optical fiber terminal box integrates the function of splicing and splitting, suitable for the straight through or branch connection and terminal connection in optical system, protecting connection for cables and distribution pigtails. The cables can be spliced with indoor cables by splitting to meet the requirement of traditional network.
Click:424

Service Online:

Product Details

Datasheet Download

Features:
• High impact plastic PC+ABS, standard user interface SC
• Suitable for 1x8 PLC splitter
• Anti-UV, shocking resistance.
• Wall mounted application with screws
• IP-54 protection level for indoor use.


Specifications:

Material: PC+ABS
Dimensions (HxWxD): 210x125x47mm
Max. Capacity:

8 SC simplex adapter

Inlet: 2 ports
Outlet: 8 ports
Installation way: Wall Mounted (indoor)
