Product Details
Datasheet DownloadFeatures：
• Water-proof design with IP65 Protection level
• Manage fibers in a reasonable fiber radius condition
• Fiber bend radius control more than 40mm
• 1*16 micro type splitter can be installed
• Suitable for the fusion splice
• Easy to maintain and extend the capacity
Specifications:
|
Model |
EC18-I001 |
|
Dimensions (H x W x D.) |
316 x 250 x 126mm |
|
Type |
Inline Type (Horizontal Type) |
|
Seal Type |
Mechanical |
|
Number of Inlet Ports |
4 Ports (round cable) |
|
Cable Diameter |
Φ5mm– Φ16mm |
|
Outlet Cable Diameter |
Round: 16 cables 4.5-5.3mm; Flat: 16 cables 2-3mm |
|
Capacity of Splice Tray |
24 fibers |
|
Quantity of Splice Tray |
1pc |
|
Capacity of Splitting Tray |
1*16 splitter |
|
Quantity of Splitting Tray |
1pc |
|
Body Material |
PP |
|
Splice Tray Material |
ABS |
|
Application |
Aerial, Wall or Pole Mounting |
