Product Details
Datasheet DownloadFeatures：
• IP68 Protection
• Suitable for protection fiber cable splices
• Slots for mini type splitter body
• Resistance to vibration, UV and temperature fluctuation
• Sealing structure silicon gum material
• Easy re-enter without any tools, saving time and cost
• Rugged construction for long term reliability
Specifications:
|
Model |
EC18-I004 |
|
Dimensions (H x W x D.) |
330 x 248 x 125mm |
|
Type |
Inline Type (Horizontal Type) |
|
Port number of cable entrance |
4 Ports + 8 drop ports with integrated SC adapters |
|
Cable diameter |
Round:7-12mm; Flat:2*3mm |
|
Max. Capacity |
36 Ports |
|
Capacity of Splice Tray |
12 fibers |
|
Quantity of Splice Tray |
3pcs |
|
Body Material |
PP |
|
Splice Tray Material |
ABS |
|
Application |
Aerial Mounting |
