Datasheet DownloadFeatures：
• Low Insertion Loss
• Low PDL
• Compact Design
• Good channel-to-channel uniformity
• Wide Operating Wavelength: from 1260nm to 1650nm
• Wide Operation Temperature
• High Reliability and Stability
Specifications:
Table 1 (1xN PLC Splitter)
|
Parameters |
1x2 |
1x4 |
1x8 |
1x16 |
1x32 |
1x64 |
1x128 |
|
|
Operating Wavelength (nm) |
1260 ~ 1650 |
|||||||
|
Fiber Type |
G652D, G657A or as per request, 0.25mm bare fiber or 0.9mm cable |
|||||||
|
Insertion Loss (dB) (Typical/ Max) |
3.8/ 4.0 |
7.2/ 7.4 |
10.5/ 10.7 |
13.5/ 13.7 |
16.5/ 16.9 |
20.5/ 21.0 |
23.8/ 24.5 |
|
|
Uniformity (dB) Max |
0.6 |
0.6 |
0.8 |
1.2 |
1.5 |
2.5 |
2.8 |
|
|
Return Loss (dB) |
APC |
≥55 |
||||||
|
UPC |
≥50 |
|||||||
|
Polarization Dependent Loss (dB) Max |
0.2 |
0.2 |
0.3 |
0.3 |
0.3 |
0.5 |
0.5 |
|
|
Directivity (dB) |
≥55 |
|||||||
|
Operating Temperature (℃) |
-40 ~ +85 |
|||||||
|
Storage Temperature (℃) |
-40 ~ +85 |
|||||||
|
Operating Humidity |
5% ~ 85% RH |
|||||||
|
Storage Humidity |
5% ~ 85% RH |
|||||||
