Product Details
Datasheet DownloadFeatures:
Low insertion loss and back reflection capability
Bayonet style (stick and twist) housing for easy connection
Nickel plated metal body corrosion resistant
Zirconia ceramic ferrule available in several performance grades
Specifications:
|
Specification |
ST Connector |
||
|
Single-mode |
Multi-mode |
||
|
UPC |
APC |
PC |
|
|
Insertion Loss (dB) |
≤0.3 |
≤0.3 |
≤0.3 |
|
Return Loss (dB) |
≥50 |
≥55 |
≥20 |
|
Fiber Count |
Simplex |
||
|
Boot Size |
0.9mm, 2.0mm, 3.0mm |
||
|
BootColor |
Blue (UPC) Green (APC) Black/ Red (MM) |
||
|
Operationg Temperature |
-20 ~ +70℃ |
||
|
Storage Temperature |
-40 ~ +80℃ |
||
